Gain the versatility to create your ideal workspace and boost your AI PC productivity with support for up to 4 displays, up to 130W power delivery, and multiple ports to connect all your peripherals.
With Dell Pro Smart Docks, reduce IT efforts by scheduling updates during off-hours, while ensuring fleetwide firmware compliance and eliminating end user interruptions.
Most manageable
Elevate the IT management experience with no software or PC connection required, allowing you to remotely manage all your Dell Pro Smart Docks.
Remotely manage your smart docks without end-user presence from the Dell Device Management Console - the industry's first holistic peripheral management solution[2] that configures, deploys, and updates smart docks over Wi-Fi.
Keep users working confidently with enterprise-grade WPA-3 192-bit encryption for secure Wi-Fi communication. Safeguard your sensitive data with tamper-resistant, hardware-based encryption built into your Dell Pro Smart Dock.
Effortless maintenance
Reduce IT efforts by scheduling updates during off-hours, while ensuring fleetwide firmware compliance and eliminating end user interruptions. Learn More
Configure your workspace to your liking with a USB-C cable that can be routed left or right.
Connect your way
Configure your workspace to your liking with an ambidextrous USB-C cable[4] that can be routed left or right.
Designed for sustainability
The Dell Pro Smart Dock is built with at least 65% post-consumer recycled materials[5] and packaged with 100% recycled or renewable packaging.[6]
Ports and slots
Front side
USB-A 3.2 Gen 2 with PowerShare
USB-C 3.2 Gen 2
Rear side
HDMI 2.1
DisplayPort 1.4
DisplayPort 1.4
USB-C 3.2 Gen 2 Multifunction DisplayPort 1.4
USB-A 3.2 Gen 2 with PowerShare
USB-A 3.2 Gen 2 with PowerShare
USB-A 3.2 Gen 2 with PowerShare
2.5 Gigabit Ethernet (RJ45)
Power In
Tech Specs
Technical Information
Connectivity Technology
Wired
Number of Displays Supported
4
Management Features
MAC Address Pass-through
PXE Boot
Dock Power Button Sync
Wake-on-LAN
WLAN to LAN Switch
Kernel Direct Memory Access (DMA) Protection
Dell Command Update (DCU)
Port Disablement
Device Supported
Notebook
Video
Video Resolution
DP1.4 without Display Stream Compression Up to:
4 x HD (3840x2160) @ 60Hz
3 x FHD (1920x1080) @ 60Hz
2 x QHD (2560x1440) @ 60Hz
1 x 4K (3840 x 2160) @ 60Hz
DP1.4 with Display Stream Compression
4 x WQHD (3440 x 1440) @ 60Hz
3 x WQHD (3440 x 1440) @ 60Hz
2 x 5K (5120 x 2160) @ 60Hz
1 x 6K (6144 x 3456) @ 60Hz
Network & Communication
Ethernet Technology
RJ45 Ethernet port, 2.5GbE
Interfaces/Ports
Interfaces
Video interfaces
2 x DP1.4
1 x HDMI 2.1
1 x USB-C 3.2 Gen 2 Multi-function DisplayPort 1.4
USB Ports (Data Only)
4 x USB-A 3.2 Gen 2 (10 Gbps)
1 x USB-C 3.2 Gen 2 (10 Gbps)
USB Ports (Power)
4 x USB-A 3.2 Gen 2 (4.5W each)
1 x USB-C 3.2 Gen 2 (15W)
1 x USB-C Multi-function DisplayPort (7.5W)
All deliver power with or without PC
USB Power Delivery
96W
Software
Operating System Supported
Windows 10
Windows 11
Ubuntu
Red Hat Enterprise Linux
ChromeOS
macOS
Power Description
Maximum Power Supply Wattage
180W
Physical Characteristics
Height
20.5cm
Width
9cm
Depth
3.52cm
Weight (Approximate)
562 g
Miscellaneous
Package Contents
Docking Station
Power Adapter and Power Cord
Documentation (Quick Start Guide, Safety, Environmental, and Regulatory Information)
Kensington Security Slot
Yes
Warranty
Limited Warranty
3 Year
Additional Warranty Information
3-Year Limited Hardware Warranty with Advanced Exchange
